Maximum number of parking spaces in a minimum of space – WÖHR Combiparker 560

The semi-automatic parking system for maximum space efficiency in urban areas

The Combiparker 560 combines a compact design with impressive versatility: with up to five parking levels and freely configurable layouts of up to four levels stacked vertically, it enables the creation of a high-capacity car park even on the most confined sites. Ideal for residential complexes, commercial buildings or inner-city projects where every square metre counts.

Up to 76.5% less space required compared to a traditional underground car park
Up to 750 flexible design options – suitable for almost any plot layout
Platform load capacity of up to 3,000 kg – also suitable for modern, heavy-duty vehicles

GO TO THE PRODUCT PAGE

REQUEST A CONSULTATION NOW

How does the Combiparker 560 work?

The Combiparker 560 is a semi-automatic parking system that organises vehicles across multiple levels in a particularly space-saving manner. To achieve this, the system uses horizontal and vertical movements to position parking spaces as if in a clever sliding puzzle. An empty space serves as a flexible area through which platforms can be shifted sideways and then moved up or down. This automatically brings the selected parking space to the entry level – completely behind closed, locked gates for maximum security.

The Combiparker is conveniently operated via an RFID chip, remote control or smart parking app, whilst the system carries out all movements autonomously. With up to five levels, various platform widths, selectable vehicle heights and a total of up to 750 variants, the Combiparker 560 offers an exceptionally flexible solution for modern, space-saving car park planning.

Enable Youtube content

Yes, I would like to have content from Youtube displayed. I agree that by doing so, my personal data will be passed on to the operator of the portal from which the content originates, so that they can analyze my behavior. You can find more information in our privacy policy

Accept

The main benefits

Prefabrication & short construction time thanks to standardised modules.
Less excavation & construction volume → lower risks associated with groundwater, underpinning and logistics.
Reduced on-site emissions (noise/dust/traffic), which is beneficial for the neighbourhood & local authorities.
Planning certainty thanks to tried-and-tested systems and defined interfaces (structural engineering, building services, fire protection).

Modular & scalable: variable widths/heights/grid sizes; integration into complex floor plans.
Ideal for city centre locations: fits into narrow plots, courtyards or mixed-use areas.
Flexible access concepts: entry/exit from the street, internal or combined; clear traffic flow.
Integration into the design: façade, gate and lighting options for a cohesive appearance.

Applications of the WÖHR Combiparker 560

Housing & Multi-family dwellings
Ideal for creating additional parking spaces where space is limited – particularly where parking spaces are permanently allocated.
Inner-city projects requiring high levels of densification
Suitable for urban locations where conventional underground car parks take up too much space.
New-build projects
Flexible integration into different floor plans and building geometries; can be implemented above or below ground.

Existing buildings & Infill development
An efficient solution for increasing parking capacity without major structural alterations.
Compact underground car parks
Ideal for garages with limited width or depth, as the Combiparker allows parking without the need for driveways.
Projects with a focus on cost-effectiveness
Requires less space and involves lower construction costs compared to conventional parking solutions.

SAVING RESOURCES THROUGH STACKED PARKING

COMBIPARKER 560 - NEW!

The ´Combiparker 560´ is comparable to the Combilift and also offers the possibility of storing vehicles in an extremely compact way by raising, lowering and
and moving the parking pallets crossways.

However, thanks to a special technology, the Combiparker 560 allows cars to be parked on up to 5 levels - with just one parking level.

Surface area
Width 19,05 m x length 33,70 m at approx. 642 m²
Underground levels
5
Parking spaces Combiparker
58
Parking spaces Conventional underground car park
63
Parking Space Parking system
Length 6,00 m, width 2,70 m, height 2,05 m
Parking space conventional
Length 5,20 m, width 2,65 m
